Description
ENGINE
Cylinders/Material
2/Cast-iron sleeve
Lubrication
Fully pressurized automotive-style oil pump w/ spin-on oil filter
Engine Type
24 HP professional-grade Kohler® V-Twin OHV
MOWER DECK
Deck Style/Construction
11-gauge, floating, fabricated w/ 7-gauge reinforced plate
Deck Lift
Hand lever adjustment w/ spring-assist
Cutting Width/Blades
48″ triple-blade (high-lift)
Deck Wash
Patented SmartJet™ high-pressure deck washing system
Anti-Scalping
2 greasable heavy-duty gauge wheels
Deck Attach/Removal
QuickAttach™ in seconds (no tools required)
Deck Cutting Height
1″ – 4″ (in .25″ increments)
OPERATION
Engine Start
Electric
Seat
18″ high-back seat w/ armrests
Safety Systems
Operator presence, RevTEK™ reverse mowing technology
PTO Clutch
Electronic fingertip engagement
ELECTRICAL SYSTEM
Alternator
12V – 15 amp regulated
Battery Voltage
230 cold crank amp
GENERAL
Hour Meter
Standard electronic
ADDITIONAL SPECIFICATIONS
Fuel Tank Capacity
Single 2.8-gallon tank
Reverse Speed
3 mph
Overall Length
70″
Approximate Weight
730 lbs.
Forward Speed
7 mph
Engine Oil Capacity
2 qt.
Wheelbase
43″
POWER SYSTEM
Cruise Control
Standard/Foot operated
FRAME
Frame
Heavy-duty 12-gauge reinforced fully welded 1-piece full-length steel frame
COMFORT & CONTROL
Steering
Steering wheel control w/ quick-adjust tilt column
SPECIFICATIONS
Turning Radius
Zero
Cup Holder
Standard
STEERING
Front Axle
Fabricated, greasable
WARRANTY
Warranty
3-year/No Hour Limit
ENGINE & DRIVE SYSTEM
Transmission
Dual Hydro-Gear® ZT-2800™ w/ oil reservoir and filter
WHEELS & SUSPENSION
Parking Brake
Foot pedal w/ mechanical locking
