Description
Engine
- Engine Brand Cub Cadet®
- Engine Model Twin OHV EFI
- Engine Displacement 679cc
- Fuel Tank Capacity 2.5 gallon. Easy fill, large opening
- Cylinders/Material Twin/Cast-iron sleeve
- Engine Start Easy push-button engine start
- Engine Oil Capacity 2 qt.
- Lubrication Fully pressurized automotive-style oil pump w/ spin-on oil filter
- Battery 300 cold crank amps
- Charging System Flywheel alternator – 15 amp regulated
Drive System
- Forward Speed 5.5 mph
- Reverse Speed 3.1 mph
- Rear Axle 3/4″ w/dual PM steel drive hubs
- Transmission Housing Cast aluminum
- Engine to Transmission Heavy-duty belt
Cutting Deck
- Deck Cutting Width 46″
- Deck Wash Patented SmartJet™ high-pressure deck washing system
- Deck Material 11-gauge fabricated steel
- Deck Attach/Removal QuickAttach™ (no tools required)
- Deck Engagement (PTO) Electronic fingertip engagement
- Deck Construction Fabricated deck
- Spindle Construction 3/4″ with steel cap and Triple Lip Sealed
- Blade(s) Twin Blades
- Deck Lift Lever/12-position/spring-assisted
- Cutting Height Range 1″ – 4″
- Anti-Scalping 2 Ball/2 Narrow
Chassis
- Frame Fully robotically-welded frame with new e-coating corrosion defense system (5-year limited warranty)
- Turning Radius 16″
- Front Tires 15″ x 6″ ball bearing
- Rear Tires 20″ x 8″
- Tire Tread Multi Trac
- Bumper Single-tube
Controls
- Cruise Control Soft touch engagement
- Direction Optimized steering system, manual sector and pinion/16″
- Brakes Automotive-style disc
- Headlight(s) LED High Illumination
Comfort
- Seat Type Cub Comfort™ high-back seat with 10 degree incline and slide
- Arm Rests Standard
Dimensions
- Dimensions L/W/H 68″/50″/42.5″
- Weight (approx.) 580 lbs.
Additional Specifications
- Mulch Kit Optional
- Model Number 13AZA1CN010
Warranty
- Warranty 3-year unlimited hours (includes powertrain)
- Front Axle Warranty 5-year chassis & front axle unlimited hours/limited lifetime fabricated deck shell
