Description
Engine
- Engine Brand Kawasaki
- Engine Model FS Series
- Engine Displacement 725cc
- Engine Output 24 hp
- Fuel Tank Capacity 3.5 gal.
- Cylinders/Material Twin
- Engine Start Key
- Engine Oil Capacity 2.1 qts.
- Lubrication Fully pressurized
- Battery 12V 230 cold crank amps
- Charging System 15 Amp Regulated
- Governor Manual
- Choke Separate choke and throttle
- Air Filter Dual element
- Oil Filter Yes
Drive System
- Transmission Hydrostatic, dual
- Forward Speed 7.5 MPH
- Reverse Speed 3.5 MPH
- Rear Axle 1″
- Transmission Housing Cast Aluminum
- Transmission Type Hydro-Gear ZT 3100
Cutting Deck
- Deck Cutting Width 60″
- Cutting Modes Discharge/mulch/bagging
- Deck Wash Included
- Deck Material Steel, 11-gauge, reinforced
- Deck Attach/Removal Removable
- Deck Engagement (PTO) Pull knob (electric)
- Deck Construction Fabricated
- Spindle Construction Sealed cast aluminum housing (Maintenance free)
- Blade(s)3
- Deck Lift Foot pedal with Dial Adjust
- Cutting Height Range 1” – 4.5”
- Anti-Scalping 2 ball, 1 nose
- Deck Positions 15 positions
Chassis
- Frame 2” x 2” tubular steel frame
- Front Axle(s) Steel
- Front Caster Mount Sealed ball bearings
- Turning Radius 0″
- Front Tires 11″x6″-5″
- Rear Tires 20″x12″-10″
- Tire Tread Turf Master/Multi Trac
- Rear Tow Hitch Included
- Corrosion Protection Triple Guard Corrosion Defense System™
- Yokes 5/16″ steel
Controls
- Brakes Lap bar integrated
- Steering Wheel Control Lap bars
- Headlight(s) 2 – LED
- Display Hour meter
Comfort
- Seat Type 24″ high back seat
- Arm Rests Included
- Seat Suspension Advanced polymer
- Seat Adjustment Lever
- Floor Mats Rubber
- Steering Comfort Quick adjustable (no tools) Soft Touch lab bars
Additional Specifications
- Mulch Kit Optional
- Discharge Chute Included
- Cup Holder Included
- Operator Presence System Included
- Bagger Optional
Warranty
- Warranty 3-year/unlimited hour warranty
- Frame Warranty Limited lifetime warranty
- Deck Shell Warranty Limited lifetime warranty
