Description
Engine
- Battery 56 v-60 Ah-3000 Wh
Drive System
- Transmission Electric, foot controlled
- Forward Speed 5.5 mph
- Reverse Speed 3.1 mph
- Rear Axle 3/4″ w/dual PM steel drive hubs
- Transmission Housing Cast aluminum
Cutting Deck
- Deck Cutting Width 42″
- Cutting Modes Side discharge/mulch/bagging
- Deck Material 13-gauge stamped steel
- Deck Attach/Remova lQuickAttach™ (no tools required)
- Deck Engagement (PTO) Push button electric
- Deck Construction 13-gauge steel, stamped
- Blade(s) Twin blade
- Deck Lift Manual/12-position/spring-assisted
- Cutting Height Range 1″ – 4″
- Anti-Scalping 4 anti-scalping deck wheels
Chassis
- Frame Fully robotically-welded frame with new e-coating corrosion defense system (5-year limited warranty)
- Front Axle(s) Heavy-duty 3/4″ through machined bushings
- Front Caster Mount Heavy-duty cast-iron (5-year limited warranty/unlimited hours)
- Turning Radius 16″
- Front Tires 15″ x 6″ sleeve bearing
- Rear Tires 20″ x 8″
- Tire Tread Turf Saver
Controls
- Cruise Control Push button engagement
- Direction Optimized steering system, manual sector and pinion
- Steering Wheel Control Steering wheel w/ quick-adjust tilt column
- Headlight(s) LED
Comfort
- Seat Type Cub Comfort™ high-back seat with 10 degree incline and slide
- Arm Rests Standard
Dimensions
- Dimensions L/W/H 68″/50″/42.5″
- Weight (approx.) 410 lbs.
Additional Specifications
Warranty
- Warranty3-year unlimited hours (includes powertrain)
- Front Axle Warranty4-year battery/5-year unlimited hours chassis and front axle warranty
