Product Description
SPECIFICATIONS
ENGINE & DRIVE SYSTEM
Transmission
Dual Hydro-Gear™ ZT-2800™ w/oil reservoir and filter
quickly leaves your lawn with a professional-quality finish
Engine Type
Kawasaki FR Series V-twin OHV
Horsepower / CC’s
23 HP – 726cc
Ground Speed
7.5 mph Fwd / 3.5mph Rev zero-turn controlled ground speeds quickly leave your lawn with a professional-quality finish.
Fuel Capacity
3.5 Gallon fuel tank capacity to keep you mowing and minimize time loss for refueling needs
MOWER DECK
Deck Height Adjustment
Foot pedal with spring assist creates the perfect cut
15 Positions
Cutting Height
1” – 4.5” leads to a precise event cut
Spindle Construction
Sealed cast aluminum housing (maintenance-free)
Deck Blades
Triple Blade deck blades
meaning fewer clumps and stragglers, finer clippings and increased evenness.
Deck Size/Type
54” Fabricated Aeroforce
Deck Material
A heavy-duty 11-gauge fabricated deck with reinforced leading edges, 1” x 3/18” trim side and an AeroForce™ cutting system has been independently tested and proven to deliver a best-in-class cut. Protected by the Cub Cadet Triple Guard Corrosion Defense System™ with E-Coat.
Deck Wash
SmartJet deck wash system provides high pressure water that cleans out grass and debris build-up under the deck
Leading Edge Reinforcement
Reinforced 1” x.375” welded steel bar stock
OPERATION
Seat Type
Automotive-inspired, ergonomic, fully adjustable premium 18” high-back seat and a durable, advanced polymer seat suspension system optimizes comfort while reducing operators fatigue
Lap Bar / Steering Wheel Control
3- way adjustable ergonomic lap bar design with integrated parking brake, and Mow-in-Reverse. Provides comfort with a simple operation
Park Brake / Braking
Intergrated system in Lap Bars for ease of use
Rear Tires
20”x12”-10″ Turf Master premium rear tires offer excellent traction, minimize turfing and provide a better ride on uneven ground at higher speeds
Front Tires
13″x 6.5″-6″ smooth tread front wheels pivot 180 degrees without turf damage
PTO Engagement
Electronic fingertip blade engagement PTO allows for smooth operation of the deck or attachments
Cruise Control
N/A
Headlight
Illuminating Dual-LED Headlights provide ultimate vision for mowing in low light conditions
CHASSIS
Frame
High-strength, continuous square 2” x 2” tubular steel frame with fully E-Coat lower frame and Triple Guard Corrosion Defense System™ protects against wear and tear.
Front Axle / Yokes
Fixed 2″ x 2.5″ fully welded tubular steel axle (e-coated) / 5/16″ steel yokes provide premium strength
Rear Bumper
2″ x 2″ Tubular steel bumper
ROPS
N/A
Rear Hitch
Standard
DIMENSIONS
Dimensions L/W/H
80” x 65” x 48”
Weight (approx)
615 lbs.
WARRANTY
Warranty
The Strongest Warranty in it’s class
3-year / unlimited-hour warranty. Plus, limited lifetime warranty on frame and fabricated deck shell.
