Honda WT20

$1,199.00

SKU: 554 Category: Tag:

Product Description

Engine GX160
Displacement 163 cc
Bore and stroke 2.7″ x 1.8″
Compression Ratio 9.0:1
Oil Alert Std
Pump type Trash Centrifugal Self-priming
Volute Rigid Mounted Cast Iron w/ Stainless Wear Plate
Impeller Conical Cast Iron
Mechanical Seal (Pump case / impeller) Silicon Carbide/Silicon Carbide
Priming time 60 sec. @ 16.4 ft.
Drive system Direct
Discharge capacity 185 gal/min
Suction port diameter 2″
Discharge port diameter 2″
Total head lift 85 ft.
Suction head lift 26 ft.
Maximum pressure 37 psi
Solids handling 13/16 inches
Dimensions (LxWxH) 24.4″ x 18.1″ x 18.3″
Dry weight 104 lbs.
Fuel Capacity 0.82 gal
Run Time @ Max Discharge 1.5 hr
Strainer Part # 78325-YG0-003
Residential Warranty 3 years
Commercial Warranty 3 years
